New Switchcraft Sealed Cable Gland Cord Grips released

17th August 2020

New Switchcraft Conxall Sealed Cable Gland Cord Grips released for easy connectivity in wet and harsh environment applications. Available now from leading Switchcraft UK Distributor - CIE Electronics.

Switchcraft - leading manufacturer of professional and industrial cables & connectors - has released the latest in their range of Conxall harsh environment connectors - the CG range of Sealed Cable Gland Cord Grips.


With a high ingress protection rating of IP68, these sealed connnectors are the easiest solution to attach cables to any devices requiring extremely reliable water or dust ingress protection.

Ideal for wet and harsh environment applications

The Switchcraft Conxall CG connector range provides the ideal connectivity solution in a wide range of harsh and wet envionment applications including outdoors, marine, clean room, medical, food processing, automotive and data logging equipment.

Switchcraft Conxall CG range

Simply by tightening the nut of the CG connector range compresses the strain relief, thereby ensuring a strong grip and preventing the cable from being pulled away from your connected device.

The Switchcraft CG Cord Grips are available in a variety of sizes to accomodate cable diameters from 4mm through to 16mm - as well as the ability to accomodate multiple cables through a single gland.

Specifications

Seal Rating:  IP68
Temp.Rating:  -40°C to 100°C
Shell Material:  Thermoplastic
O Ring Material:  Silicone
Seal Material:  Silicone

Switchcraft CG Series Order Codes

PART NUMBER THREAD SIZE CABLE OPENINGS ACCEPTED CABLE DIAMETER
CGM12N26 M12 x 1.25 1 4.0mm to 6.5mm
CGM16N35 M16 x 1.5 1 6.0mm to 9.0mm
CGM20N44 M20 x 1.5 1 5.5mm to 11.2mm
CGM20N63 M20 x 1.6 1 8.0mm to 16.0mm
CGM25N63 M25 x 1.5 1 10.0mm to 16.0mm
CGM25N24X2 M25 x 1.5 2 3.0mm to 6.0mm
CGM25N24X3 M25 x 1.5 3 3.0mm to 6.0mm
CGPLUG44 Cap for CGM20N44 - -

Contact the CIE Electronics team for more information

CIE is the main UK distributor for the complete range of Switchcraft and Conxall professional connectors and cables. Please contact the team today for full details, product pricing or samples.

Download the Switchcraft CG Series connector PDF
